Full automatic folder gluer - Welldoing trading limited
|
WD-2400
|
WD-2800
|
||
|
max working size
|
2400x12000mm
|
2600x1200mm
|
|
|
min working size
|
800x300mm
|
800x300mm
|
|
|
speed
|
120pcs/min
|
120pcs/min
|
|
|
machine length
|
15×2.8×1.4m
|
15×3.5×1.4m
|
|
|
power
|
7.9kw
|
10.5kw
|
|
corrugated cardboard folder gluer equipment adopts full computer control, which is easy and simple to operate
Adjust the size in 3-5 minutes and change the order quickly
The paper feeding section adopts synchronous belt suction to ensure that the cartons are not skewed
Automatic folding gluing machine can stick three-layer and five-layer cartons
full automatic folding gluing machinery adopts automatic counting, stacking and quantitative output.
automatic feeder unit:
1 Vacuum suction feeding to feed warping paperboard easily:
2 Quality electromagnetic clutch and brake adopt, feeding section controlled independent, operation easily:
3 Scorer wheel adjustable, suit for 2-8mm thick paperboard;
4 Second creasing structure can impress again the paperboard which was not creased well.
folder gluer unit:
1 Simple structure and high reliability, glue quantity adjustable, cleaning easily;
2 Stainless steel glue wheel adopted, long life and saving glue cost;
3 Imported quality rubber belt adopted, automatic folding;
4 With paperboard rectify device and creasing rectify device.
counter stacker unit:
1 Stacking and counting are simple and reliable;
2 Digital control, operation easily and reliable. No-stop put in data and automatic counting;
3 With rectification function;
4 Paperboard counting and put out by pneumatic, stable and quickly.
Our Services
1. OEM service are available.
2. Trade Manager online, also contact by Email.
3. To solve problems by pictures/videos.
4. Engineers are available service abroad.
FAQ
1. Are you a factory or trading company?
We are both a factory and a trading company in this field .
2. What is the terms of payment you accept?
We usually accept the T/T payment, we need 30% of total amount as deposit,
pay the 70% balance before delivery, but we can also accept the L/C.
3. How does your factory do regarding quality control?
Quality is priority. We always regard great importance to quality controlling from the very small thing(even a small screw we will choose the best quality) from the beginning.
