corrugated carton gluing machine - Welldoing trading limited

Short Description:

The automatic box folding gluing machine is composed of three parts: vacuum paper feeding part, gluing folding part and counting stacking output part. Digital display control, PLC computer amplitude modulation, dual frequency conversion synchronous operation, with simple, fast, reliable and accurate control mode. Automatic paper feeding, automatic gluing and folding, automatic counting, automatic stacking output, average gluing speed of 150m / min, high speed, energy saving and labor saving.


Product Detail

Product Tags

Main Features
1,The average velocity is 8000-10000pieces/h, speed fast, greatly improve productivity.
2,Automatic paper feeding, automatic gluing, automatic folding, automatic correction, automatic counting, only two people can complete the whole process.
3,Air suction belt feeding mode, simple structure, fast speed, accurate paper feeding.
4,The paper feeding is accurate by means of the belt feeding.And with the secondary indentation function, make the carton folding more accurate.
5,With the function of secondary rectification, eliminate the size of the port and reduce the reject rate.
6, Automatically correct the carton right angle, 180 degree correction, effectively correct the scissors fork
7,Automatic counting, shaping, stacking into code, full code output, fast speed, high precision.
8,PLC program control and touch screen, adjusted automatically according to the input order parameter

model 2400mm 2600mm 2800mm
max.paperboard 900x2200mm 1200x2400mm 1200x2600mm
min.cardboard 300x800mm 300x800mm 300x800mm
overall size 12800x2850x2250mm 12800x3050x2250mm 12800x3250x2250mm
power 10kw 11kw 12kw

Salient features:
1. The degree of environmental protection is high and conforms to the development of the social times. It is conducive to the recycling of old cartons by paper enterprises. It can be beaten directly without nail removal, which is conducive to environmental protection;
2. Low cost. Compared with the nail box process, the use of adhesive can greatly reduce the cost than the use of nail box flat wire. Especially in recent years, with the continuous emergence of rubber powder and new processes, and the rising price of steel, there is an account between the two;
3. The carton will not be damaged or corrugated, which can relatively improve the strength of the carton and is conducive to the long-distance transportation of packaged products;
4. It is more conducive to prevent the contents from being scratched by nails, especially the contents of soft or liquid objects, such as fresh milk boxes;
5. It can greatly improve the production efficiency, especially the full-automatic box gluing machine, which can save manpower. One box gluing machine can replace three box nailing machines;
6. It can be matched with the corresponding printing unit to form a "one-stop" configuration of carton production line.

Paper feeding Department
1. The air suction and paper feeding mode at the front edge of the belt is accurate and reliable.
2. High grade electromagnetic clutch and electromagnetic brake system are adopted, so that the paper supply department can be controlled independently and the operation room is single and reliable.
3. The height of the paper pressing wheel is adjustable, and the thickness of the paperboard is 2-8mm.
4. Linked with the folding part, frequency conversion speed regulation, paper feeding speed 0-150m / min.
5. The front baffle and paper feeding belt of the paper feeding part are adjustable on the left and right.

Gluing folding part
1. The main motor adopts frequency conversion speed regulation system, which has no noise, flexible and stable speed regulation.
2. Imported high friction belt is used to transport paperboard, which is automatically stacked.
3. Stainless steel wheel is used for gluing, with uniform glue amount, no fault and glue saving.
4. The folding part is equipped with paperboard correction device and indentation correction device.
5. The folding part has two rows of adjustable inner positioning guide wheel system, with higher forming accuracy.
6. Folding speed: 0-150 / min.

Counting and stacking Department
1. Automatic stacking and neat output.
2. The main motor of the technology department is variable frequency speed regulation, the speed is adjustable, and the startup is stable and reliable.
3. The cartons are transported by belt and stacked neatly at a speed of 0-130m / min.
4. Use the clapping board to hit the large carton, which has the function of deviation correction, and the deviation is very small.
5. Counting and pushing out adopt pneumatic mode and PLC electric control, with reliable, accurate and fast action.
6. PLC programming controller and touch screen digital control are adopted, with simple operation, reliable action, non-stop input of data and automatic counting. 7. The output part adopts the synchronous pressing mode of the bottom conveyor belt and the upper pressing belt to make the finished carton stick firmly and output neatly without dislocation.

hgfh (1)

hgfh (2)

hgfh (3)

hgfh (4)

hgfh (5)

hgfh (6)
