The semi-automatic carton folder gluer machine can be divided into two types: the first type is widely used in China, which is mainly used for folding, gluing, shaping, conveying, pressurizing, counting, drying and other functions of cartons. The whole machine is composed of feeding section, gluing section, shaping section, conveying and pressurizing section, receiving and counting section, etc. The operation procedure is that the worker manually folds the processed whole piece of cardboard and sends it to the gluing section. The gluing section automatically applies glue to the cardboard bonding section. After the roller is sent to the reshaping section to reshape one by one to a certain amount, the automatic transmission pressurization, drying and final completion are completed. This semi-automatic carton gluing machine is applicable to the outer packing box with standard folding flap in one box, and the carton must be pressed well along the corrugated “folding line”, otherwise the glued carton may produce waste products. This machine is very suitable for the cardboard after die cutting, and its maximum folded cardboard size is 1200mm × 1200mm, minimum 400mm × 400mm, the production speed is 50~70 tablets per minute.

Another kind of semi-automatic box gluing machine is evolved by virtue of the structure of the box pasting machine. This box gluing machine is composed of an automatic feeding section, a grinding and gluing section, a conveying section, and a manual folding and pressurizing section. The workers fold and press them manually, and then put them into the pneumatic work department for compaction after reaching a certain number. Its feature is that the automatic feeding speed of the feeding section is fast, but the folding cardboard can not be fed, and only the flat board can be fed. The feeding section of this kind of carton sticking machine is similar to the front feeding structure. It is fed by special tape, roller, etc. At the same time, it can also complete the bonding of two pieces of cardboard into a box, and can complete the bonding of special cartons such as special-shaped cartons and side entry cartons. Its grinding and gluing part can accurately roughen and glue the parts to be glued, and can also use the nozzle configured by the machine to spray glue locally on the profiled box. There are 12 working positions on both sides of the machine, which can be operated by 12 workers at the same time. The production speed is also considerable.

In the normal production process, once the carton machinery breaks down, it is the production department that is most affected, but why does the production department pay no attention to the equipment? On the one hand, this is related to the original equipment management mechanism of the company. The division of work is too detailed, and the maintenance of equipment is in the charge of maintenance workers; On the other hand, it is related to the work schedule of the production department. The production department usually only does what must be done in production, and does not contact with the equipment.

However, it is difficult to reduce equipment failure, even close to zero failure, only with the efforts of the equipment department, but only with the assistance of the production department. That is to say, the production department should do some work that should be done, namely, cleaning, spot inspection, oiling, screw inspection and tightening, and replacement of other parts. Through these activities, abnormalities can be found as early as possible. The concerted efforts of the two departments are a must. Therefore, it is very important to make the personnel in the production department care about equipment maintenance and do what they should do. Most failures have certain symptoms before they occur. The observation methods of these minor symptoms can be taught to the operators so that they can find the failures as early as possible, and the operators can be taught the basic methods of cleaning, spot inspection and refueling, thus prolonging the period of equipment failures. Therefore, how to improve the initiative of operators to participate in the maintenance of equipment and give full play to their collective strength is the key and common difficulty to reduce equipment failures.
