automatic folder gluer machine

In the packaging industry of full automatic carton folder gluer machine, corrugated boxes with the advantages of recyclable paper materials have been vigorously promoted and supported [1]. In order to meet the needs of the market, the corrugated machine is constantly developing towards the direction of high-speed. As the core of the pressure roll mechanism, new mechanisms are also emerging to meet this demand. A roll changing mechanism is developed for the automatic box folder gluer machine. When maintenance is required, the automatic box folder gluer machine can easily replace the pressure roll.

The bonding strength of the automatic case sticking machine is closely related to the vibration of the pressure roller. If the amplitude of vibration is too large, the corrugated board will form high and low pits (the indentation is deeper than the indentation), which seriously affects the bonding strength of the corrugated board. In view of the vibration problem of the corrugated machine, many scholars have carried out relevant research. The automatic box folding gluing machine analyzes the center distance between the automatic box folding gluing machine and the pressure roll, establishes the mathematical equation of the center distance, and calculates the acceleration of the center distance change.

Recently, a new type of pressure roll mechanism has been developed in the market of automatic box folder gluer machine. The position of the pressure roll is adjusted by servo electric cylinder and eccentric wheel, and the vibration of the pressure roll is reduced under the joint action of the bag cylinder and hydraulic cylinder.

However, in the early stage, the mechanism of the automatic box folder gluer machine was a combination of cylinders, cams and limit rods. The production personnel adjusted the contact position of the cams and limit rods based on experience to maintain a reasonable pressure on the pressure rolls. The effect was not ideal for a long time, which was difficult to meet the performance requirements of the products, and the adjustment efficiency was slow. In order to overcome the above shortcomings, the fully automatic box folder gluer machine has developed a combined structure of bag cylinder, electric push rod and ejector pin. The position of the pressure roller can be adjusted by controlling the electric push rod. However, due to the insufficient pressure of bag cylinder and the rigidity of ejector pin, the pressure roller vibrates excessively and the electric push rod is easy to be damaged.

The resonance of the single side corrugated machine is studied by the automatic box folder gluer machine. The analysis shows that when the linear speed reaches 180 m/min, the resonance is very strong, and the quality of the cardboard produced is very poor. The automatic box carton folding gluing machine simplifies the upper and lower automatic box folder gluer machines into a single degree of freedom vibration system, and takes the variation of ideal center distance during the meshing process of the upper and lower automatic box folder gluer machines as the displacement excitation to obtain the dynamic response of the automatic box folder gluer machine. The full automatic box folder gluer machine has built a dynamic model of the old pressure roll mechanism. The full automatic box folder gluer machine has analyzed the reason for the resonance of the mechanism, but has not made a quantitative analysis of the vibration response.
